Description
Accentra (formerly Yale) AU4608LN ANSI/BHMA Grade 2 Certified Cylindrical Lock, Classroom Function, Augusta Lever
The 4600LN Series is certified to ANSI/BHMA Grade 2 standards and is UL fire-listed for all functions, ensuring reliability and peace of mind.
ANSI Function F84 – Deadlocking latch bolt by levers. Outside lever is locked by key in outside lever. Inside lever is always free.
- Versatile: Field reversible handing and other product options offer flexibility in many commercial applications
- Economical: Priced affordably to suit projects of all budgets
- Secure: Quality security from a trusted brand for over 170 years
- Strong & Reliable: ANSI/BHMA Grade 2 certified for long life and reliability
Specifications
| Brand | Accentra |
|---|---|
| Finishes | 605 Bright Brass, 606 Satin Brass, 613e Dark Oxidized Satin Bronze equivalent, 625 Bright Chrome, 626 Satin Chrome, BSP Black Suede Powder Coat |
| Cylinder & Keys | 6-pin conventional, keyed different, with 2 keys |
| Backset | 2-3/4″ |
| Handing | Non-Handed |
| Fire Rating | UL-cUL fire rated up to 3 hours |
| ADA Compliance | Meets ADA requirements – A117.1 Accessibility Code |
| Latch | 1/2” throw, deadlocking – 1-1/8″ x 2-1/4″ face |
| Lock Function | Classroom |
|---|---|
| ANSI/BHMA Standard | Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, Grade 2 |
| Keyway | Accentra/Yale E1R (Para) Keyway, Schlage C Keyway |
| Strike | 4-7/8” x 1-1/4” ASA/ANSI strike with curved lip to meet ANSI A115.2 door frame preparation |
| Door Thickness | 1-3/8″ to 1-3/4″ |
| Usage | Medium Duty |
| Lever Design | AU (Augusta) |
| Warranty | 3 Year |
